Dee Shackle Galvanised Steel 5 – 24mm
Product Description
Hot Dip Galvanised Commercial Dee shackle in a range of sizes
These shackles have a screw collared pin which is removable from the Dee shaped shackle body they are ideal for maritime use, dee shackle is narrower than a bow or anchor shackle The smaller loop is designed to take high loads primarily in line. and can be used for many application
A mm | p mm | L mm | J mm | BL kg |
5 | 5 | 19,50 | 10 | 400 |
6 | 6 | 24,00 | 12 | 500 |
8 | 8 | 32,00 | 16 | 1000 |
10 | 10 | 40,00 | 20 | 1600 |
12 | 12 | 49.00 | 25 | 2600 |
14 | 14 | 55.00 | 27 | 2900 |
16 | 16 | 64,0 | 32 | 4000 |
20 | 20 | 80,0 | 38 | 5500 |
24 | 24 | 95.00 | 50 | 7000 |
