Description
Barton Series 3 Block.
A strong, lightweight range of blocks for use on dinghies and day boats or as lead blocks on a larger craft. With a plain bearing block with a precision molded Acetal sheave running on a large diameter brass bearing, ensuring free running under the highest of loads. Featuring a flexible plastic spring for anti-tumble action and becket. Fitted with a Kevlar ‘K’ cam with fully adjustable cam arms by the locking clevis pin to achieve the correct cleating angle. Particularly useful for mainsheet, vang tackles or down-hauls.
Product Code : BTN003571
Additional information
Weight | 1.05 kg |
---|---|
Part No. | 03 571 |
Length | 136mm |
Weight | 261g |
Sheave Size | Ø45mm X 12mm |
Max. Line Ø | 10mm |
Safe Working Load | 385Kg (848lbs) |
Breaking Load | 770Kg (1690lbs) |
